Light-Display Modul for the Light-Interface with 40 light outputs with 0.5A each.

Light-Display-Module	Light-Display	file	edition
Assembly instruction	Kit	PDF	09/2022
Operating instruction	Kit and finished module	PDF	09/2022

Light-Power Modul for the Light-Interface with 24 light outputs with 2.5A each.

Light-Power-Module	Light-Power	file	edition
Assembly instruction	Kit	PDF	09/2022
Operating instruction	Kit and finished module	PDF	09/2022

Connection cable (0.5m, 1m or 2m) for the Light-Display and the Light-Power Module if an installation distance of 0.5m, 1m or 2m is required instead of a direct connection.

Cable	Kabel Light@Night	file	edition
Operating instructions	Connection cable Kabel L@N 0,5m	PDF	09/2022
	Connection cable Kabel L@N 1m	PDF	09/2022
	Connection cable Kabel L@N 2m	PDF	09/2022

Light-Display-(from version 1.7) and Light-Power-Module (from version 1.2) can be as well connected to each other via patch cable.
All examples are available on the following page: sample connections for Light@Night and sample connections for Light-DEC

Subject to technical changes and errors.
